0.28 Inch 1 Digit 7 Segment LED Display And Dp

This 0.28-inch, one-digit, seven-segment LED display with Dp and seven segments is the ideal way to show numbers and symbols on your electronic projects. This LED display, which has seven distinct segments and a decimal point (DP), is bright and clear.

This LED display has a straightforward style that will blend in perfectly with your projects and is easy to install. It is a great option for projects that need a low power draw because it also has a low power consumption.

Premium materials were used in the construction of this LED display to guarantee dependable operation and long-term use. The DP is constructed with a high-intensity chip to guarantee a bright and clear display, while the segments are composed of a sturdy and scratch-resistant material for increased longevity.

Our 0.28 Inch 1 Digit LED 7 Segment Display with Seven Segment and DP is a flexible part that can be utilized in many different applications because it is compatible with a variety of circuits and devices.

0.28 Inch 1 Digit 7 Segment LED Display with Seven Segment and Dp with super bright color from sanqi company, suitable for easy mounting on PC boards or sockets. 12 inch seven segment display is designed for applications that require low power consumption. They are tested and selected for the excellent low current characteristics to ensure that the segments are matched at low current.



0.28 Inch 1 Digit 7 Segment LED Display And Dp has excellent visibility and contrast. The LEDs provide consistent brightness throughout the display and are suitable for PC board and slot mounting.





Part No. (Angular pins)		Chip			IV@IF=20mA		Iv@IF=20mA
Common Cathode	Common Anode	Material	Color	WLD	One Seg		One DP
					Min.	Typ.	Min.	Typ.
LD2811EUR	LD2811FUR	AlGaInP	Ultra Red	640	30	45	30	45
LD2811EUO	LD2811FUO	AlGaInP	Ultra Orange	625	45	60	45	60
LD2811EUA	LD2811FUA	AlGaInP	Ultra Amber	605	30	45	30	45
LD2811EUY	LD2811FUY	AlGaInP	Ultra Yellow	595	30	45	30	45
LD2811EUG	LD2811FUG	AlGaInP	Ultra Green	573	30	45	30	45
LD2811EPG	LD2811FPG	InGaN	Pure Green	525	120	300	120	300
LD2811EUB	LD2811FUB	InGaN	Ultra Blue	470	30	45	30	45
LD2811EW	LD2811FW	InGaN	Ultra White	\	100	120	100	120
Unit:	\	\	\	nm	mcd	mcd	mcd	mcd
