0.4 Inch Single Digit 7 Segment LED Display

Product Description

0.4Inch Single Digit Numeric SMD LED Display with 10.16mm dight height and surface mount type



1.Product Description:
Ultra Thin than Through-hole led display
Common Cathode or common anode SMT Display
RoHS and REACH Compliant
High intensity and excellent reliability Digital Display
High quality, Low power consumption
IC compatible , Easy assembly

2. Outer Dumension and Internal Circuit Diagram:

3. Summary:

Digit Height	0.4 inch digit height
Available Emitting color	Red, yellow-green, orange, amber, yellow, pure green, blue, white,Purple or Customized color
Available Face color	Red, white, grey, and black.
Available Segment Color	Red, white (milky),water clear, and yellow.
Available Electrode	Common anode or common cathode



4. What emitting color you can have?

Part No.		Chip			Iv@IF=20mA
Common Cathode	Common Anode	Material	Color	WLD	Per Chip
					Min.	Typ.
LSD4010AR-G	LSD4010BR-G	AlGaInP	Super Red	640	-	8
LSD4010AUR-G	LSD4010BUR-G	AlGaInP	Ultra Red	620	-	15
LSD4010AO-G	LSD4010BO-G	AlGaInP	Orange	605	-	40
LSD4010AY-G	LSD4010BY-G	AlGaInP	Yellow	580	-	50
LSD4010AG-G	LSD4010BG-G	AlGaInP	Green	570	-	16
LSD4010APG-G	LSD4010BPG-G	InGaN	Pure Green	520	-	35
LSD4010AB-G	LSD4010BB-G	InGaN	Blue	470	-	25
LSD4010AW-G	LSD4010BW-G	InGaN	White	x0.27/y0.25	-	60
Unit:	\	\	\	nm	mcd	mcd



5. What max voltage and current you can use to drive it?

Parameter	Electrical optical Characteristics[1]			Absolute Maximum Ratings[1]
Emitted color	Forward Voltage @ IF=20mA		Reverse Current VR=5V	Power Dissipation	DC Forward Current	Peak Forward Current[2]
Per Chip	Typ.	Max.
Super Red	2.0	2.6	30	60	20	100
Ultra Red	2.0	2.6	30	65	20	100
Orange	2.0	2.6	30	65	20	100
Yellow	2.0	2.6	30	65	20	100
Green	2.0	2.6	30	75	20	100
Pure Green	3.0	3.6	30	85	20	100
Blue	3.0	3.6	30	85	20	100
White	3.0	3.6	30	85	20	100
Unit:	V	V	uA	mW	mA	mA

Emitted brightness: Customers can choose standard brightness or high brightness version to meet different visual needs.
Emitted color: A variety of emission color options are available, such as red, orange, yellow, green, blue, etc., to suit different application scenarios and aesthetic preferences.
Model number color: Model number color can also be customized to meet specific design requirements.
Font: Custom fonts are supported to meet specific display needs.
Common cathode/anode: Customers can choose common cathode or common anode configuration to suit different circuit design needs.



When installing and using the 0.4-inch single-digit seven-segment LED display, the installation guide and instructions for use provided by the manufacturer should be followed.
Ensure that the driving voltage and current of the display are within the specified range to avoid damage to the display.
When used in groundwater environments, appropriate protective measures should be considered, such as waterproofing and sun protection.
